Platform Scale

Platform Scale

Optional Accessories

Auxilary Display

Hi-Low Indicator

Data Printer

Test Weights

Features

  • Easily perform the following :
    – Net – Gross Formula
    – Piece Counting function
    – M+ & Memory recall Function
    – Weighing Mode : Litter / gm / kg.
    – Peak – Hold Function
    – Hi – Low for check weighing
  • 0.8” SEGMENT LED display for easy view.
  • Optional RS232 Interface for connecting Serial Printer or PC .
  • Customize Platform size, design, MOC (stainless steel / Mild steel) Capacity & Functions are available on request.
  • Equipped Rust proof, Wheather Proof Loadcells for accurate results in any wheather.
  • Option : Weighing Controller with RS485 Modbus, Hi-Low Relay, Analogue Output – 4~20mA, Inbuilt Printer with Real Time Clock and many more options available on request.

Specifications

MODELCAPACITY (KG)REPEATABILITY (G)READABILITY (G)PAN (MM)
CWS 1001001010400 x 400 mm
CWS 2002002020400 x 400 mm
CWS 3003005050600 x 600 mm
CWS 5005005050600 x 600 mm
CWS 1T1T1001001000 x 1000 mm
CWS 2T2T200200or
CWS 5T5T500500Custom Size on request

Design & Specification are subject to change without any prior notice.
