Digital Ultrasonic Cleaner

Digital Ultrasonic Cleaner

Ultrasonic Cleaner Function

KINGLAB ultrasonic cleaner operate at 40kHz frequency. These high frequency sound waves convent the electrical energy in to ultrasonic wave in the from of vibration by means of PEIZO transducers. The accumulation of ultrasonic waves products millions of microscopic cavitation bubbles. These cavitation bubbles drives the cleaning solution in to components to be cleaned, removing away, all the dirt and accumulated residues on them.

Salient Features

  • Inner Tank & Outer body Made of Stainless steel – SS304 grade
  • Sloped bottom – for easy drain
  • Rust and corrosion proof.
  • Uniform and constant output.
  • Dynamic PEIZO Transducers (with High Velocity Focussing Head)
  • Digital Red LED Display
  • Scratch Proof Film on Outer Cabinet
  • Digital timer & Temperature function
  • Feather touch keyboard.
  • Moisture Proof PCB


  • All Laboratories, automobile & Components Industrial
  • Watches / Lens / frames and glasses, Diamond and Jewellery
  • O.T. Surgical and Hospital equipments, Electronic PCB’s, Bearings
  • Fuel Injection and Parts, Inkjet cartridges


Capacity3 Litres6 Litres
Tank Size (LXWXH) mm240 x 140 x 100300 x 150 x 150
Overall Size (LXWXH) mm270 x 170 x240330 x 180 x 310
Ultrasonic Power100 W150 W
Heating Power100 W300 W
Drain ValueNOYES
Time Setting0 to 20 minutes0 to 20 minutes
Heating temp.0 – 60 0C0 – 60 0C
DisplayDigital RED LED 7 SegmentDigital RED LED 7 Segment
Ultrasonic Frequency(kHz)40 kHz40 kHz
Lid MaterialSS 304SS 304
Inner Tank MaterialSS 304SS 304
Outer Tank MaterialSS 201SS 201
Power SupplyAC 220V / 50 HZAC 220V / 50 HZ
Weight (appox.)4.8 kg9 kg

Design & Specification are subject to change without any prior notice.

Standard Accessories : Lid, Basket, Main Instrument
